MECHANICAL

  • Height: 1.75″
  • Width: 19.00″
  • Depth: 22.00″
  • Weight: 23.5 lbs

PROCESSORS

  • 1 or 2 Intel® Xeon® processor E5-2600 v3 product family CPUs

INTERCONNECT

  • 2 Intel Quick Path Interconnect (QPI) channels: 6.4, 8.0, and 9.6 GTps

CHIPSET

  • Intel C610 series

MEMORY

  • 24 DDR4 DIMM slots
  • Support for DDR4 registered RDIMMs and LRDIMMs
  • Advanced error-correcting code (ECC)
  • Independent Channel Mode
  • Mirrored Channel Mode
  • Lockstep Channel Mode

PCIe SLOTS

  • 2 PCIe Generation 3.0 slots:
    • Riser 1: One full-height, 3/4-length slot with x24 connector and x16 lane
    • Riser 2: One half-height, half-length slot with x24 connector and x16 lane

EMBEDDED NIC

  • Dual 1-Gbps Intel i350 Ethernet ports

MODULAR LOM

  • The mLOM slot can flexibly accommodate 1-Gb, 10-Gb, or 40-Gbps adapters

(mLOM) Power

  • Hot-pluggable, redundant 770W power supplies. Optional DC supply.

Supplies Cisco FlexFlash

  • The server supports up to 2 internal 32-GB or 2 internal 64-GB Cisco FlexFlash drives (SD cards) on which you
    can install an OS or a hypervisor. The second SD card can be used to mirror the first.
  • Cisco FlexFlash SD cards also support Utility mode with out-of-band update of utility partitions.

INTERNAL USB

  • The server supports 1 internal USB flash drive

CISCO IMC

  • Integrated Baseboard Management Controller (BMC)
  • IPMI 2.0 compliant for management and control
  • One 10/100/1000 Ethernet out-of-band management interface
  • CLI and WebGUI management tool for automated, lights-out management
  • KvM

FRONT PANEL CONNECTOR

  • One KvM console connector (supplies 2 USB, 1 vGA, and 1 serial connector)

FRONT PANEL LOCATOR LED

  • Indicator to help direct administrators to specific servers in large data center environments.

ADDITIONAL REAR CONNECTORS

  • Additional interfaces including a vGA video port, 2 USB 3.0 ports, an RJ45 serial port, 1 Gigabit Ethernet management port, and dual 1 Gigabit Ethernet ports.

RAIL-KIT OPTIONS

  • MIL Grade Rackmount 20” slides
  • Non-ball bearing General Devices
  • Optional Jonathan Slides.

OPERATING SYSTEMS

  • Microsoft Windows Server 2012 R2
  • Microsoft Windows Server 2012
  • Microsoft Windows Server 2008 R2
  • Red Hat Enterprise Linux
  • Novell SUSE Linux Enterprise Server
  • Oracle Linux (Unbreakable Enterprise Kernel (UEK)
  • Oracle Solaris
  • Ubuntu Server
  • CentOS
  • Virtualization
    • vMware vSphere ESXi
    • Oracle virtual Machine Server (UEK)
    • Citrix XenServer

COOLING

  • High CFM, low decibel

MECHANICAL

  • Height 3.5″
  • Width 17.75″
  • Depth 22.00″
  • Weight 40 lbs

CPU

  • Intel CPU Architecture Options
  • Intel Xeon Scalable processors (Skylake-SP)
  • Upgradable to two processors
  • Embedded long-life road map

EXPANSION SLOTS

  • One (1) full-height
  • Two (2) half-height 3/4 length slots
  • Multiple PCIe slot combinations available

DRIVE BAYS

  • 8 hot swap removable Drive Bays (2.5″ form factor hard drives or SSDs)
  • One slim line SATA CD/DVD (R/W) available with SSDs or SAS HDDs

MEMORY

  • 16 DIMM Slots (Up to 512GB with 16x32GB DIMMs)

MOUNTING OPTIONS

  • 22” Slide Rails
  • Fixed mounting rails front and rear
  • Extend to 28″

POWER SUPPLY OPTIONS

  • 900W Dual Redundant 110/220 VAC Supply
  • 700W Single 28VDC Supply

MECHANICAL

  • Height: 2.5 (standalone), 4.25 (Router + GigE Switch)
  • Width: 5.25 (standalone), 5.25 (Router + GigE Switch)
  • Depth: 7.0 (standalone), 7.0 (Router + GigE Switch)
  • Weight: <5.0 lbs. (standalone), <10 lbs. (Router + GigE Switch)

CISCO TECHNOLOGY

  • Integrated Cisco 5915 Embedded Services Router (ESR) PCI-104 Card
  • Cisco Enterprise IOS- Base Image or Advanced Services Image (pre-loaded)
  • Support for IPv6 Routing, VoIP / CME, VPN / Firewall / IPS, Mobile IP, IPsec Exclusive to Advanced IOS only

PORTS
Standard Router

  • 2x 10/100 Mbps Fast Ethernet WAN Router Ports, IEEE 802.3 Compliant
  • 3x 10/100Mbps Fast Ethernet Switched LAN Ports, IEEE 802.3u Compliant
  • 1x Console Port, RS232

Router + Integrated GigE Switch

  • 2x 10/100 Mbps Fast Ethernet WAN Router Ports, IEEE 802.3 Compliant
  • 3x 10/100Mbps Fast Ethernet Switched LAN Ports, IEEE 802.3u Compliant
  • 15x 10/100/1000Mbps GigE Switched LAN Ports, IEEE 802.3u Compliant
  • 2x Console Ports, RS232 (1x for Router, 1x for GigE Switch)

Cooling

  • Fully conduction cooled milled aluminum chassis CORE thermal ducting for optimal heat transfer to outside of chassis

POWER SUPPLY OPTIONS

  • 24 / 28VDC Voltage Input Range: 18-33 VDC
  • Power Consumption: <15W Max (Router),
  • <50W Max (Router + GigE Switch)

MOUNTING OPTIONS

  • Option 1 (std): Screw mount side flanges
  • Option 2: Slotted side flanges for straps
  • Option 3: Custom mounting flanges are available

OPTIONS

  • Starter Cable Set (MIL-38999 to RJ-45/DB9)
  • Custom Cable Set (Customer Specified)

MECHANICAL

  • Height 3.5
  • Width 17.4
  • Depth 22 (can be mounted in racks up to 36 depth)
  • Weight 22Lbs.

CISCO TECHNOLOGY

  • Integrated Cisco Catalyst 4948E Ethernet Switch (refer to Cisco.com for a full list of specifications)
  • Cisco IOS Software- Enterprise Services, IP Base or LAN Base Image (pre-loaded)
  • Support for Layer 2 and 3 Forwarding, EEM, QoS, IPv6 Switching and Routing, Extended MAC address table to enable server virtualization

PORTS

  • 48x 10/100/10000 Gigabit Ethernet (BASE-T) Downlinks (over Copper)
  • 2x 10 Gigabit Ethernet (10GBASE-CX4) Uplinks, Compatible w/ Copper Twinax Media
  • 1x 10 Gbps Multi-mode Fiber (10GBASE-LRM), Compatible w/ 62.5 micron / 500 modal Bandwidth
  • 1x 1 Gbps Multi-mode Fiber (1000BASE-SX), Compatible w/ 50.0 micron / 500 modal Bandwidth
  • 1x EIA/TIA-232 Serial Console (Out-of-band management)
  • 1x 100BASE-T Management Ethernet (In-band management)

COOLING

  • 80mm high speed, high volume fans (4 rear mounts)
  • Thermostatically controlled via a Core Systems HeatSense fan controller

RELIABILITY

  • 24 / 28VDC Voltage Input Range: 18-33 VDC
  • Power Consumption: <15W Max (Router), <50W Max (Router + GigE Switch)

POWER

  • 24 / 28VDC Voltage Input
  • Power Consumption: <320W Max

OPTIONS

  • Starter Cable Set (MIL-38999 to RJ-45/DB9)
  • Custom Cable Set (Customer Specified)
