Rugged 2U DL180RS

Rugged HPE Servers

The Rugged DL180RS 2U server is based on the HPE industry leading DL180 Server platform and has a 22.00″ short depth chassis. By using the Hewlett Packard Enterprise (HPE) industry-leading ProLiant DL180 Server platform, the Core Systems GEN10 DL180RS is a cost-effective, fully rugged compute platform designed to operate in harsh environments.

  • Utilizes the latest HPE ProLiant and Intel® Chipset technology offerings, setting the new standard in rugged computing performance.
  • Up to 2 of the latest Intel Xeon® processors, up to 12 cores, and 16 DIMM slots of DDR4 Smart Memory (up to 512GB).
  • Provides up to 6 PCIe 3.0 riser slots for GPU and network cards as well as up to 16 SFF drives for expanded platform capabilities.

Datasheet

  • Utilizes the latest HPE ProLiant and Intel® Chipset technology offerings, setting the new standard in rugged computing performance.
  • Up to 2 of the latest Intel Xeon® processors, up to 12 cores, and 16 DIMM slots of DDR4 Smart Memory (up to 512GB).
  • Provides up to 6 PCIe 3.0 riser slots for GPU and network cards as well as up to 16 SFF drives for expanded platform capabilities.

Datasheet
Height 3.50 in
Width 17.75 in
Depth 22.00 in
Weight 31.00 lbs
CPU 4th Gen Intel Xeon Scalable Processor, 4th Gen Intel Dual Xeon Scalable Processor, 13th Gen Intel Core i9 Processor
External Bays 16
Power 110-220VAC, 28VDC, 700W, 900W
Chassis Type Lightweight aluminum chassis
RAM Up to 2TB
Expansion Slots Qty: 1, full height
Environmental Specifications Tested to meet military environmental specifications.
Operational Temperature MIL-STD-810F, Method 501.5 Procedures I/II; -15°C to +55°C
Storage Temperature MIL-STD-810F, Method 501.5 Procedures I/II; -15°C to +55°C
Humidity MIL-STD-810F, Method 507.4; 48 Hour, 95% RH 40-65C (with conformal coat option)
Altitude MIL-STD-810F, Method 500.4; 12,500ft operation with 40,000ft transport
Vibration MIL-STD-810G, Method 514.6 Procedure I; 4.43 GRMS, 5-20000Hz, 60min/axis
Shock MIL-STD-810G, Method 516.6, Procedures I/V; 20g, 11msec - functional shock; 40g, 11msec crash hazard shock
Other MIL-STD-461F CE & RE emissions (with 461 filter option)
Environmental Specifications Tested to meet military environmental specifications.
Operational Temperature MIL-STD-810F, Method 501.5 Procedures I/II; -15°C to +55°C
Storage Temperature MIL-STD-810F, Method 501.5 Procedures I/II; -15°C to +55°C
Humidity MIL-STD-810F, Method 507.4; 48 Hour, 95% RH 40-65C (with conformal coat option)
Altitude MIL-STD-810F, Method 500.4; 12,500ft operation with 40,000ft transport
Vibration MIL-STD-810G, Method 514.6 Procedure I; 4.43 GRMS, 5-20000Hz, 60min/axis
Shock MIL-STD-810G, Method 516.6, Procedures I/V; 20g, 11msec - functional shock; 40g, 11msec crash hazard shock
Other MIL-STD-461F CE & RE emissions (with 461 filter option)
