Rugged RPS217D

The RPS217D is a rugged MIL-Spec 16-Core server with a 17.3" HD LCD screen & machined aircraft aluminum chassis designed to thrive in hostile environments.

DATASHEET REQUEST QUOTE

RPS217D Rugged Laptop

The Core Systems RPS217D is a rugged MIL-Spec 16-Core portable server with a machined aircraft aluminum chassis designed to thrive in hostile environments. The portable server has a 17.3” HD LCD, 16-Core Xeon CPU, 128GB RAM and 8 SSD drives. The Core Systems RPS217 is unrivaled in rugged server performance.

The Core Systems RPS217D portable server is engineered for high shock/vibration and temperature. The RPS217D provides true server-class performance while utilizing the onboard PCIe RAID card for high security storage intensive applications.

3.9" Height
11.4" Depth
16.5" Width
18.41 lbs Weight

DATASHEET REQUEST QUOTE

Technical Specifications

Environmental Specifications:	Operational Temperature Range: MIL-STD-810F/G, Method 501.5, Procedures I/II; -10C to +50C with solid state drives Storage: MIL-STD-810F/G, Method 501.5, Procedures I/II; -40C to +75C Humidity: MIL-STD-810F/G, Method 507.4; 48 hour, 95% RH 40-65C with humidity option Altitude: MIL-STD-810F/G, Method 500.4; 12,500ft operation with 40,000ft transport Vibration: MIL-STD-810F/G, Method 514.6 Procedure I; 4.43 GRMS, 5-20000Hz, 60min/axis with solid state drives Shock: MIL-STD-810F/G, Method 516.6, Procedures I/V; 20g, 11msec functional shock; 40g 11msec crash hazard shock Other: MIL-STD-461F/G CE102 & RE102; Meets using CORESYSTEMS optional 461 EMI Kit
Mechanical:	Height - 3.9 in (9.9 cm), Width - 16.5 in (41.91 cm), Depth - 11.4 in (28.9 cm), Weight - 18.41 lbs (3.62 kg)
CPU:	Intel® Xeon® processor D-1587; 16-Core, 32 Threads; Intel® Hyper-threading with Turbo Boost (Optional 12-Core or 8- Core CPU configurations)
Display:	17.3” TFT LCD FHD (1920 x 1080); 500 NITS; A/R optically bonded glass
Memory:	Supports up to 128GB DDR4 RAM
Storage:	Qty 2, 2.5” SSD Drives (Supports 1.98TB, 3.84TB, 7.68TB capacity SSD drives) W/ Onboard CAC reader
Keyboard/Mouse:	Waterproof membrane 88-key keyboard; Sealed touchpad

Environmental Specifications:
Operational Temperature Range: MIL-STD-810F/G, Method 501.5, Procedures I/II; -10C to +50C with solid state drives Storage: MIL-STD-810F/G, Method 501.5, Procedures I/II; -40C to +75C Humidity: MIL-STD-810F/G, Method 507.4; 48 hour, 95% RH 40-65C with humidity option Altitude: MIL-STD-810F/G, Method 500.4; 12,500ft operation with 40,000ft transport Vibration: MIL-STD-810F/G, Method 514.6 Procedure I; 4.43 GRMS, 5-20000Hz, 60min/axis with solid state drives Shock: MIL-STD-810F/G, Method 516.6, Procedures I/V; 20g, 11msec functional shock; 40g 11msec crash hazard shock Other: MIL-STD-461F/G CE102 & RE102; Meets using CORESYSTEMS optional 461 EMI Kit
Mechanical:
Height - 3.9 in (9.9 cm), Width - 16.5 in (41.91 cm), Depth - 11.4 in (28.9 cm), Weight - 18.41 lbs (3.62 kg)
CPU:
Intel® Xeon® processor D-1587; 16-Core, 32 Threads; Intel® Hyper-threading with Turbo Boost (Optional 12-Core or 8- Core CPU configurations)
Display:
17.3” TFT LCD FHD (1920 x 1080); 500 NITS; A/R optically bonded glass
Memory:
Supports up to 128GB DDR4 RAM
Storage:
Qty 2, 2.5” SSD Drives (Supports 1.98TB, 3.84TB, 7.68TB capacity SSD drives) W/ Onboard CAC reader
Keyboard/Mouse:
Waterproof membrane 88-key keyboard; Sealed touchpad
