Rugged 1U DL360RS

Rugged HPE Servers

The rugged DL360RS GEN10 1U standard depth rugged server is based on the HPE industry leading DL360 Server platform. Updated to Gen 10 plus and Gen 11.

  • Rugged 1U/2-socket rackmount design.
  • Supports the 4th Gen Intel® Xeon® Processor Scalable Family
  • Up to 28x cores
  • 2666 MT/s HPE DDR4 SmartMemory supporting up to 3.0 TB max.
  • 12x NVDIMMs and 10x NVMe

Datasheet

  • Rugged 1U/2-socket rackmount design.
  • Supports the 4th Gen Intel® Xeon® Processor Scalable Family
  • Up to 28x cores
  • 2666 MT/s HPE DDR4 SmartMemory supporting up to 3.0 TB max.
  • 12x NVDIMMs and 10x NVMe

Datasheet
Height 1.75 in
Width 17.75 in
Depth 27.50 in
Weight 27-34 lbs
CPU 4th Gen Intel Xeon Scalable Processor, 4th Gen Intel Dual Xeon Scalable Processor
External Bays 8
USB Ports 4
Power 900W
Chassis Type Lightweight aluminum chassis
RAM 256GB, 512GB, 1TB
Expansion Slots Qty: 1, full height
Environmental Specifications Tested to meet military environmental specifications.
Operational Temperature MIL-STD-810F, Method 501.5 Procedures I/II; -15°C to +55°C
Storage Temperature MIL-STD-810F, Method 501.5 Procedures I/II; -15°C to +55°C
Humidity MIL-STD-810F, Method 507.4; 48 Hour, 95% RH 40-65C (with conformal coat option)
Altitude MIL-STD-810F, Method 500.4; 12,500ft operation with 40,000ft transport
Vibration MIL-STD-810G, Method 514.6 Procedure I; 4.43 GRMS, 5-20000Hz, 60min/axis
Shock MIL-STD-810G, Method 516.6, Procedures I/V; 20g, 11msec - functional shock; 40g, 11msec crash hazard shock
Other MIL-STD-461F CE & RE emissions (with 461 filter option)
Environmental Specifications Tested to meet military environmental specifications.
Operational Temperature MIL-STD-810F, Method 501.5 Procedures I/II; -15°C to +55°C
Storage Temperature MIL-STD-810F, Method 501.5 Procedures I/II; -15°C to +55°C
Humidity MIL-STD-810F, Method 507.4; 48 Hour, 95% RH 40-65C (with conformal coat option)
Altitude MIL-STD-810F, Method 500.4; 12,500ft operation with 40,000ft transport
Vibration MIL-STD-810G, Method 514.6 Procedure I; 4.43 GRMS, 5-20000Hz, 60min/axis
Shock MIL-STD-810G, Method 516.6, Procedures I/V; 20g, 11msec - functional shock; 40g, 11msec crash hazard shock
Other MIL-STD-461F CE & RE emissions (with 461 filter option)

Application-Specific

Built Rugged to Last Long

Application-Specific

Built Rugged to Last Long

2019-Core-Systems-Datasheet-1U-G10-DL360RS.pdf

Related Product Designs

All products can be customized to your specs and requirements.

Request A Quote Today

Fill out the form for pricing and information

Military-Ready Design

Rugged 1U DL360RS Features

Rugged Chassis

Built with an all-aluminum chassis designed to handle any extreme.

Powerful CPU

We provide the latest computing technology to give you the edge you need out in the field.

Built for Expansion

With room for expansion, your system has the versatility your mission requires.

Rugged 1U DL360RS

Technical Specifications
Height 1.75 in
Width 17.75 in
Depth 27.50 in
Weight 27-34 lbs
CPU 4th Gen Intel Xeon Scalable Processor, 4th Gen Intel Dual Xeon Scalable Processor
External Bays 8
USB Ports 4
Power 900W
Chassis Type Lightweight aluminum chassis
RAM 256GB, 512GB, 1TB
Expansion Slots Qty: 1, full height

Rugged 1U DL360RS

Military Testing
Operational Temperature MIL-STD-810F, Method 501.5 Procedures I/II; -15°C to +55°C
Storage Temperature MIL-STD-810F, Method 501.5 Procedures I/II; -15°C to +55°C
Humidity MIL-STD-810F, Method 507.4; 48 Hour, 95% RH 40-65C (with conformal coat option)
Altitude MIL-STD-810F, Method 500.4; 12,500ft operation with 40,000ft transport
Vibration MIL-STD-810G, Method 514.6 Procedure I; 4.43 GRMS, 5-20000Hz, 60min/axis
Shock MIL-STD-810G, Method 516.6, Procedures I/V; 20g, 11msec - functional shock; 40g, 11msec crash hazard shock
Other MIL-STD-461F CE & RE emissions (with 461 filter option)

Application-Specific

Built Rugged to Last Long

Application-Specific

Built Rugged to Last Long

Rugged 1U DL360RS
