Rugged Servers

Rugged M217S (FIO)

The M217S-FIO is a rugged 1U server with a front I/O and is made for applications that require short-depth solutions. The Rugged M217S-FIO server has been tested to meet military specifications.

  • Rugged, sheet-metal chassis
  • The M217S-FIO supports the latest Intel Quad and Hexa-Core CPUs
  • Supports single and dual redundant power supplies in both AC and DC inputs
  • Application-Specific Design
  • Military-Grade Design
  • Transit Options Available

Datasheet

  • Rugged, sheet-metal chassis
  • The M217S-FIO supports the latest Intel Quad and Hexa-Core CPUs
  • Supports single and dual redundant power supplies in both AC and DC inputs
  • Application-Specific Design
  • Military-Grade Design
  • Transit Options Available

Datasheet

Rugged Servers

Technical Specifications
Height 3.50 in
Width 19.00 in
Depth 17.00 in
Weight 34.00 lbs
CPU 4th Gen Intel Xeon Scalable Processor, 13th Gen Intel Core i9 Processor, 4th Gen Dual Intel Xeon Scalable Processor
RAM 1TB
Expansion Slots Qty: 4, full height
External Bays 5
USB Ports 4
Power 110-220VAC, 800W
Chassis Type Lightweight aluminum chassis
Environmental Specifications Tested to meet military environmental specifications.
Operational Temperature MIL-STD-810F, Method 501.5 Procedures I/II; -15°C to +55°C
Storage Temperature MIL-STD-810F, Method 501.5 Procedures I/II; -15°C to +55°C
Humidity MIL-STD-810F, Method 507.4; 48 Hour, 95% RH 40-65C (with conformal coat option)
Altitude MIL-STD-810F, Method 500.4; 12,500ft operation with 40,000ft transport
Vibration MIL-STD-810G, Method 514.6 Procedure I; 4.43 GRMS, 5-20000Hz, 60min/axis
Shock MIL-STD-810G, Method 516.6, Procedures I/V; 20g, 11msec - functional shock; 40g, 11msec crash hazard shock
Other MIL-STD-461F CE & RE emissions (with 461 filter option)
Environmental Specifications Tested to meet military environmental specifications.
Operational Temperature MIL-STD-810F, Method 501.5 Procedures I/II; -15°C to +55°C
Storage Temperature MIL-STD-810F, Method 501.5 Procedures I/II; -15°C to +55°C
Humidity MIL-STD-810F, Method 507.4; 48 Hour, 95% RH 40-65C (with conformal coat option)
Altitude MIL-STD-810F, Method 500.4; 12,500ft operation with 40,000ft transport
Vibration MIL-STD-810G, Method 514.6 Procedure I; 4.43 GRMS, 5-20000Hz, 60min/axis
Shock MIL-STD-810G, Method 516.6, Procedures I/V; 20g, 11msec - functional shock; 40g, 11msec crash hazard shock
Other MIL-STD-461F CE & RE emissions (with 461 filter option)

Application-Specific

Built Rugged to Last Long

Core Systems provides a line of Rugged Rackmount Servers that are designed and built to meet or exceed MIL-STD-810F, MIL-STD-810G, MIL-STD-461F, and MIL-S-901D specs.

Rugged Design

Battle-Proven Results

These fully-sealed short-depth servers come in a variety of sizes and are configurable and upgradeable to meet the standards needed for your mission.

2019-Core-Systems-Datasheet-M217S-FIO.pdf

Rugged Servers

Related Designs

Military-Ready Design

Rugged M217S (FIO) Features

Rugged Chassis

Built with an all-aluminum chassis designed to handle any extreme.

Powerful CPU

We provide the latest computing technology to give you the edge you need out in the field.

Built for Expansion

With room for expansion, your system has the versatility your mission requires.

Rugged M217S (FIO)

Technical Specifications
Height 3.50 in
Width 19.00 in
Depth 17.00 in
Weight 34.00 lbs
CPU 4th Gen Intel Xeon Scalable Processor, 13th Gen Intel Core i9 Processor, 4th Gen Dual Intel Xeon Scalable Processor
Expansion Slots Qty: 4, full height
External Bays 5
USB Ports 4
Power 110-220VAC, 800W
Chassis Type Lightweight aluminum chassis

Rugged M217S (FIO)

Military Testing
Operational Temperature MIL-STD-810F, Method 501.5 Procedures I/II; -15°C to +55°C
Storage Temperature MIL-STD-810F, Method 501.5 Procedures I/II; -15°C to +55°C
Humidity MIL-STD-810F, Method 507.4; 48 Hour, 95% RH 40-65C (with conformal coat option)
Altitude MIL-STD-810F, Method 500.4; 12,500ft operation with 40,000ft transport
Vibration MIL-STD-810G, Method 514.6 Procedure I; 4.43 GRMS, 5-20000Hz, 60min/axis
Shock MIL-STD-810G, Method 516.6, Procedures I/V; 20g, 11msec - functional shock; 40g, 11msec crash hazard shock
Other MIL-STD-461F CE & RE emissions (with 461 filter option)

Application-Specific

Built Rugged to Last Long

Core Systems provides a line of Rugged Rackmount Servers that are designed and built to meet or exceed MIL-STD-810F, MIL-STD-810G, MIL-STD-461F, and MIL-S-901D specs.

Rugged Design

Battle-Proven Results

These fully-sealed short-depth servers come in a variety of sizes and are configurable and upgradeable to meet the standards needed for your mission.
